HM series pressure switches have a pressure die-cast aluminium powder coated enclosure and are recommended for manifold mounting hydraulic applications.The repeat accuracy is better than +/- 1% FSR.A connection to DIN 43650 is provided for wiring.Mainly intended for high pressure hydraulic presses.
Applications
- High/Low Pressure Alarms in CNC Machines
- Compressors
- Hydraulic Power Packs
- Manifolds/stacks With Sandwich Plates
Product Features
- Compact
- Lightweight
- Three mounting styles.
- Lockable protective cap to avoid tampering(optional)
- Choice of wetted parts to suit working media.
- Electrical rating:5A,250VAC;0.2A,250VDC(res.)
