DT series pressure switches have a cast aluminium enclosure (IP54) and are recommended for panel/line mounted hydraulic/pneumatic applications. The repeat accuracy is better than +/- 2%. FSR. An electrical connector to DIN 43650 is provided for wiring. Pressure port is 1/4 inch BSP(F) standard.
Applications
- High Pressure Power Packs
- Press Applications
- Space and Defence Applications
Product Features
- Robust Construction.
- 15 A switching possible(optional)
- Panel Mounting.
- Protective lock to avoid tampering(optional)
- Electrical rating:5A,250VAC;0.2A,250VDC(res.)(optionallly 15 A,250 VAC)
