DN/DA series pressure switches are housed in pressure die cast aluminum powder coated enclosure and are recommended for panel/line mounting or outdoor service. The repeat accuracy is better than +1 1% FSR. A connector to DIN 43650 is provided for electrical wiring. Pressure port is 1/4” BSPF standard.


  • Loading , Unloading in CNC Machine(Hydraulic Applications)
  • VMC Machining Centres
  • Chuck Clamping

Product Features

  • Compact
  • Seperate Chamber for working parts
  • Choice of wetted parts to suit working media
  • Wide band adjstable differential in DA series
  • Electrical Rating : 5A,250VAC;0.2A,250VDC(res.)
