TX is a newly developed pressure transmitter with LED display. A high stable pressure sensor and a high performance specialised processing circuit are mounted in SS housing. It is stable and reliable. The TX pressure transmitter can be widely used for liquid pressure measurement in power plants, for oil hydraulics, air, steam and many other applications.

Applications:

• Power Plants
• Hydrology
• Geology Fields
• Water Treatment
• Automation

Product Specifications:

• Range : 0-0.1 bar....400 bar
• Overpressure : 1.5 FSR
• Pressure Type : Gauge / Absolute
• Accuracy : ± 0.5 % FSR
• Power Supply : 11 to 28 VDC
• Output : 4-20 mA DC (2-wire)
• Load Resistance : < (U-11)/0.02(Ώ)
• Electric Connection : DIN 43650
• Long-term Stability : ± 0.3 % FSR / year (Max.)
• Operation Temperature : - 25 to 75 o C
• Zero Thermal Drift : ± 0.1 % FSR / o C
• Storage Temperature : - 40 to 80 o C
• FS Thermal Drift : ± 0.1 % FSR / o C
• Relative Humidity : 0 to 85%
• Protection Level : IP65 Compliant
