CF Ultra low range pressure difference switches has a user adjustable knob in pascal. Differencial easily adustable with just a screwdriver.  Do not install this switch upside down with trip pressure of less than 50 Pa

Applications

• Gas Turbines
• Glass and Metal Industires
• Filteration Systems
• Burners and Furnaces
• Water Treatment Plants

Specification

• Media : Air, non-flammable gases and non-aggresive gases
• Housing Material : Body of PA 6.6 and Cover of PS
• Protection category : IP54 with cover
• Maximum working Pressure : 10 Kpa / 1019.74 mm wg
• Electrical Rating : Maximum 1.0A(0.4A)/250 VAC
• Electrical Connection : AMP flat plug 6.3 mm x 0.8 mm in accordance with DIN 462244
• Cable Entry : PG11
• Mounting Lugs : integrated in bottom Housing.
• High Pressure and Low Pressure port of Outer Diameter 6 mm
