SE series sub-miniature temperature switches are low cost options. They are generally used where size is a constraint. Typical applications are to sense temperature. Can also be used for several other applications e.g. automation, boiler, oil furnace, engine etc.

Applications:

• Automation
• Boiler
• Oil Furnace
• Engines

 Product Specifications:

• Setpoint repeatability: ± 2% of FSR
• Switch output: NO, NC, SPDT contacts.
• Enclosure: Rolled aluminium
• Storage temperature: -20°C to +80°C
• Tmax: 150°C
