MN/MA series low pressure range switches are housed in pressure die cast aluminium powder coated enclosure and are recommended for panel mounting or outdoor service based on the type of enclosure opted for. The repeat accuracy is better than +/- 2 % FSR. A 3/8 inch cable entry is provided for cables and a terminal strip suitable for wired ends is provided inside the enclosure. Pressure port is 1/4 inch BSP(F)standard.


  • Air Dryers
  • Low Vacuum Systems


Product Features

  • Separate Chamber for working parts
  • Wide band adjustable differential in MA series
  • Choice of wetted parts to suit working media
  • Electrical rating:2A,250VAC;0.2A,250VDC(res.)
  • Pressure port:1/4" BSPF
