PA series pressure difference switches are housed in pressure die cast aluminium powder coated enclosure and are recommended for panel mounting or outdoor service based on the type of enclosure opted for. The repeat accuracy is better than +/- 2% FSR.A 3/8" cable entry is provided for cables and a terminal strip suitable for wired ends is provided inside the enclosure. Pressure ports are 1/4" BSPF standard.


  • Bag Filter Operations requiring cutin/cutoff to stop and start air purging cycles

Product Features

  • Compact
  • Separate chamber for working parts.
  • Electrical rating:5A,250VAC;0.2A,250VDC(res.)
  • High pressure port: 1/4" BSPF
  • Low pressure port: 1/4" BSPF
  • Can be used for DP between (+)ve(+)ve,(-)ve (+)ve & (-)ve (-)ve pressure/vacuum.
