VS1 series vacuum swicthes are housed in pressure die cast aluminium powder coated enclosure and are recommended for panel mounting or outdoor service. The repeat accuracy is better than +/-2% FSR.A 3/8” cable entry is provided for cables and a terminal strip suitable for wired ends is provided inside the enclosure. Pressure port is 1/4” BSPF standard.


  • Vacuum Systems requiring low on-off differential

Product Features

  • Compact
  • Separate chamber for working parts
  • Electrical rating:5A,250VAC;0.2A,250VDC
  • Pressure port:1/4" BSPF
