MZ OEM pressure switches are housed in a tough polycarbonate IP 66 enclosure and are intended for outdoor use. The repeat accuracy is better than 2 % FSR. a choice of cable entries can be fitted to the enclosure. An internal earthing is provided. Terminal strip for wired ends is provided inside the enclosure. Pressure port is 1/4” BSP standard.

Applications

• Power Generation
• Burners and Furnaces
• Glass and Metal Industries
• Chemical Industries
• Steel Industry
• Hydraulic, Steam and GasTurbines
• Boilers & Compressors
• Machine tools
• Water treatment
• Sugar and Paper Mills
• Fire protection
• Surgical gas, Breweries, Milk industries
• Tyre Industry

Product Specifications

• Electrical rating : 15 Amp, 250 VAC, SPDT snapaction microswitches
• Enclosure* : IP66 standard, transparent tough polycarbonate cover
• Wetted Parts : SS 316 & Teflon
• Pressure Port : ¼ '' NPTF standard
• Cable Gland : M20 X 1.5 standard (polyamide)
• Maximum Temperature : 80 ºC maximum, Please use impulse tube for higher temperature

* IP66 is approximately equivalent to NEMA 4X
